    1 Ton Multi Grader Length Grader Rice Seed Grading Machine MDJY71/71-RF

    Product Description

    Factory supply STR MDJY71/71-RF 1 ton rice seed length grader multi grader grading machine
    Rice Length Grader is specially designed to separate one or two kinds of broken or shorter grains from whole grain by length with the indented cylinder. Broken grains which are longer than half of whole grain are difficult to separate through sieving or thickness/width grader but can be picked out by length grader.
    1 Ton Multi Grader Length Grader Rice Seed Grading Machine MDJY71/71-RF

    Product Features

    1.With high degree of precision;It can ensure that no broken rice is in the whole rice and vice versa. 2.The cylinders can be used in parallel or in series according to real requirements. 3. The process can be observe through the inspection window. 4.The sieve tube can be easily replaced and operation is simple.
    Working principle Take the principle that the whole rice and the broken rice have different lengths to separate the broken rice from the whole rice. It is assembled with rice grading sieve in flexible technological combinations (either series connection or parallel connection of expansion cylinder) to realize the grading requirements that the whole rice does not contain broken rice. The grains which are longer in length drop out of the indents before they reach the cat trough. The grains which remain in the indents are thrown into the catch trough.
    Details Images
    1 Ton Multi Grader Length Grader Rice Seed Grading Machine MDJY71/71-RF
    1 Ton Multi Grader Length Grader Rice Seed Grading Machine MDJY71/71-RF
    1 Ton Multi Grader Length Grader Rice Seed Grading Machine MDJY71/71-RF
    1 Ton Multi Grader Length Grader Rice Seed Grading Machine MDJY71/71-RF
    1 Ton Multi Grader Length Grader Rice Seed Grading Machine MDJY71/71-RF
    Product Paramenters
    Model
    MDJY50*2
    MDJY50*3
    MDJY60/60
    MDJY60*2
    Capacity(t/h)
    1.0-1.5
    2.0-2.5
    1.0-2
    2.0-2.5
    Power(kw)
    0.75*2
    0.75*3
    1.1
    1.1*2
    Upper roller size (mm)
    500*1800
    500*1800
    600*2000
    600*2000
    Lower roller size (mm)
    500*1800
    500*1800
    /
    600*2000
    Fragment in
    ≤2
    ≤2
    ≤2
    ≤2
    the whole
    Crude rice in the processed product
    ≤5
    ≤5
    ≤5
    ≤5
    Overall dimension L*W*H (mm)
    2080*720*1650
    2080*720*2450
    2770*1000*950
    2770*1000*1860
    Model
    MDJY60*3
    MDJY71/71
    MDJY71*2
    MDJY71*3
    Capacity(t/h)
    3.0-3.5
    1.5-1.8
    4-4.2
    4.5-5.5
    Power(kw)
    1.1*3
    1.5
    1.5*2
    1.5*3
    Upper roller size(mm)
    600*2000
    710*2500
    710*2500
    710*2500
    Lower roller size(mm)
    600*2000
    /
    710*2500
    710*2500
    Fragment in
    ≤2
    ≤2
    ≤2
    ≤2
    the whole
    Crude rice in the processed product
    ≤5
    ≤5
    ≤5
    ≤5
    Overall dimension L*W*H(mm)
    2770*1000*2760
    3300*1000*1050
    3300*1000*2000
    3300*1000*3040
